AUX & USB Jack (W/O Navigation/Bristol Audio) Connector End View (M12)

Fig 1: AUX & USB Jack (W/O Navigation/Bristol Audio) Connector End View (M12)

G10798215

Courtesy of KIA MOTORS AMERICA, INC.
