Door Scuff Trim Replacement

CAUTION:

Put on gloves to protect your hands.
Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface.
Take care not to bend or scratch the trim and panels.

Using a screwdriver or remover, remove the front door scuff trim (A).
(Front)

Fig 1: Front Door Scuff Trim
Courtesy of KIA MOTORS AMERICA, INC.
Remove the rear seat cushion.
Refer to REAR SEAT .
After loosening the mounting screw, then remove rear door scuff trim (A).
(Rear)

Fig 2: Rear Door Scuff Trim
Courtesy of KIA MOTORS AMERICA, INC.
Installation is the reverse of removal.

NOTE:

Replace any damaged clips.
