Check if the speedometer indicator range is within the standard values.
CAUTION:
Do not operate the clutch suddenly or increase/decrease speed rapidly while testing.
NOTE:
Tire wear and tire over or under inflation will increase the indication error.
Courtesy of KIA MOTORS AMERICA, INC. SPEEDOMETER INDICATOR RANGE [CANADA - KM/H]
| Velocity (km/h) |
Tolerance(km/h) |
| 20 |
+2.20
+0.20 |
| 40 |
+2.30
+0.30 |
| 60 |
+2.50
+0.50 |
| 80 |
+3.20
+0.70 |
| 100 |
+4.00
+1.00 |
| 120 |
+4.50
+1.50 |
| 140 |
+5.00
+2.00 |
| 160 |
+5.50
+2.50 |
| 180 |
+7.00
+3.00 |
| 200 |
+7.50
+3.50 |
| 220 |
+8.00
+4.00 |
| 240 |
+8.50
+4.50 |
| 260 |
+9.00
+5.00 |
SPEEDOMETER INDICATOR RANGE [USA - MPH]
| Velocity (km/h) |
Tolerance(km/h) |
| 20 |
+1.70
-0.20 |
| 40 |
+1.80
-0.30 |
| 60 |
+2.60
+0.60 |
| 80 |
+3.30
+0.80 |
| 100 |
+3.80
+1.30 |
| 120 |
+4.80
+1.80 |
| 140 |
+5.30
+2.30 |
| 160 |
+5.80
+2.80 |
