Inside Handle Replacement

  1. Remove the rear door trim.
  2. After loosening the mounting screws, then remove the inside handle (A).
    Fig 1: Rear Door Inside Handle & Mounting Screws
    G07380213Courtesy of KIA MOTORS AMERICA, INC.
  3. Installation is the reverse of removal.
NOTE:
  • Make sure the door locks/unlocks and opens/closes properly.
  • Replace any damaged clips.
