Repair Procedures

Removal

1. Remove the front bumper.

2. Remove the bolts and disconnect the horn connectors, then remove the high pitch horn (A) and high pitch (B).






Installation

1. Install the horns after connecting the horn connectors.
2. Install the front bumper.
