Component Inspection





P1508 Idle Speed Control Actuator Signal High of Coil #2

Inspection/Repair - Component Inspection

Component Inspection

1. Ignition "OFF"
2. Disconnect ISCA valve connector
3. Measure resistance between Close control terminal and power terminal of ISCA connector (Component side).
Specification









4. Is resistance within the specification?
