Component Inspection

P1506 Idle Speed Control Actuator Signal High of Coil #1

Inspection/Repair - Component Inspection

Component Inspection

1. Ignition "OFF"
2. Disconnect ISCA valve connector
3. Measure resistance between Open control terminal and power terminal of ISCA connector (Component side).
Specification









4. Is resistance within the specification?
