M/T (4)

MFI Control System (M/T) (4):




MFI Control System (M/T) Connector Pin Outs:




MFI Control System (M/T) Connector Pin Outs:






Previous Diagram M/T (3)

Locations: Location photographs (references to PHOTO) referred to within these diagrams can be found via the photo number at the vehicle level under Locations by Photo Number. Component Locations
