Replacement (Outside)

  1. Disconnect negative battery cable.
  2. Remove two bolts from service hole cover.
    Fig 1: Removing Bolts From Service Hole Cover
    G01100809Courtesy of KIA MOTORS AMERICA, INC.
  3. With bulb holder disengaged, pull bulb holder carefully forward relative to vehicle, and remove from light assembly. Disconnect electrical connector.
  4. Remove bulb as required from bulb holder.
  5. Install new bulb of proper type, as shown on bulb holder.
  6. Position bulb holder on light assembly and press to engage with light assembly.
  7. Install two bolts on service hole cover.
  8. Connect negative battery cable.
