Installation (Inside)

  1. Position light assembly on back panel molding assembly.
  2. Install four screws on light assembly.
    Fig 1: Installing Screws On Light Assembly
    G01100812Courtesy of KIA MOTORS AMERICA, INC.
  3. Install back panel molding assembly.
    1. Install thirteen nuts on trunk lid.
    2. Install one screw on outside of trunk lid.
    3. Connect electrical connector.
  4. Install three screws and thirteen fasteners on trunk lid trim.
  5. Connect negative battery cable.
