Fuel Pump Control Module
WARNING: This page is about a different car, the 2023 Jeep Grand Wagoneer L and 2023 Jeep Grand Wagoneer. However, it is still accessible from the selected car via links, so may be relevant.
REMOVAL
| 1 - Wire Harness Connector |
| 2 - Nuts |
| 3 - Fuel Pump Control Module |
- Raise and support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
- Disconnect the wire harness connector from the fuel pump control module.
- Remove the mounting nuts and remove fuel pump control module.
INSTALLATION
Follow the removal procedure in reverse for general reassembly of the components on the vehicle.
