Special Tools

WARNING: This page is about a different variant/trim than selected.

Courtesy of CHRYSLER GROUP, LLC	9717 - Brush, Injector Bore (Originally Shipped In Kit Number(s) 9910.)
Courtesy of CHRYSLER GROUP, LLC	8978A - Decay Tool, Fuel
Courtesy of CHRYSLER GROUP, LLC	VM.10358A - Remover, Fuel Injector
Courtesy of CHRYSLER GROUP, LLC	9340 - SAE Fuel Pump Lock Ring Wrench (Originally Shipped In Kit Number(s) 9327, 9327CC, 9397, 9575.)
Courtesy of CHRYSLER GROUP, LLC	VM.10344 - Tool, Oil Separator Remover/Installer
Courtesy of CHRYSLER GROUP, LLC	VM.10345 - Tool, High Pressure Pump Installation
Courtesy of CHRYSLER GROUP, LLC	1023 - Puller (Originally Shipped In Kit Number(s) 8678.)
Courtesy of CHRYSLER GROUP, LLC	2025400090 - Remover-Installer, Fuel Rail Bolt
Courtesy of CHRYSLER GROUP, LLC	2073300140 - Wrench, Fuel Rail Pressure Sensor
