3.0L Common Rail Diesel Engine
WARNING: This page is about a different variant/trim than selected.
The 3.0L (183 C.I.D.) six cylinder "common rail" direct injection engine is a 60° overhead valve design. The engine features are listed below:
- A cast iron cylinder block
- Aluminum cross flow cylinder heads
- Chain driven dual overhead camshafts per bank, with 4 valves per cylinder
- Central fuel injectors
- Finger Follower Actuated Valves with Hydraulic Adjusters
- Turbocharger and intercooler
- Oil Jet Cooled Pistons
- Swirl Intake Ports
- Water cooled exhaust gas recirculation, Compliance with EURO V emission regulations
- Chain driven D.O.H.C. per bank of cylinders, with 4 valves per cylinder
Cylinders are numbered front to back, beginning with the right bank. The right bank cylinders are numbered 1, 2, 3. The left bank cylinders 4, 5, 6. The fuel injection order of the engine is 1-4-2-5-3-6.
