Description And Operation: Valves
WARNING: This page is about a different variant/trim than selected.
 Courtesy of CHRYSLER GROUP, LLC
|
| 1 - Exhaust Valve |
| 2 - Intake Valve |
Both the intake and the exhaust valves are made of steel. The intake valve is 52.07 mm (2.05 inches) in diameter and the exhaust valve is 39.4 mm (1.55 inches) in diameter. All valves use three-bead lock keepers to retain the springs and promote valve rotation.
