Seat Belt-Retractor TENSIONER Rear-Right (Standard) Connector End View (D3245A)

Harness-Family: Body

Color: GREEN

Gender: FEMALE

Part Number: PPI0001144

Part Description: Not Available

Connector No: D3245A

Option: Standard

Repair Kit Part Number: 68602015AA

Cavity Count: 2

Fig 1: Seat Belt-Retractor Tensioner Rear-Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner Rear-Right Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Seat Belt-Retractor Tensioner Rear-Right Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Seat Belt-Retractor Tensioner Rear-Right Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	R36	GN/BN	0.50	2R SEAT BELT RETRACTOR PRET (+) RT	N/A
2	R38	BU/GY	0.50	2R SEAT BELT RETRACTOR PRET (-) RT	N/A
