Handle, Interior: Removal

GC0183776Courtesy of CHRYSLER GROUP, LLC
  1. Remove the front door trim panel. Refer to PANEL, DOOR TRIM, REMOVAL .
  2. Disconnect the wire harness connectors (3) as necessary.
  3. With the use of pliers or equivalent, depress the tabs on the handle cables (2) and remove from the cables from the handle housing.
  4. Remove the bezel fasteners (1).
    GC0187113Courtesy of CHRYSLER GROUP, LLC
  5. Remove the interior door handle (1) from the door trim panel.
