Section 1320 (Rear Suspension): Description
WARNING: This page is about a different car, the 2020 Jeep Renegade. However, it is still accessible from the selected car via links, so may be relevant.
As on the front, there is an independent wheel MacPherson suspension layout at the back of the vehicle.
The rear suspension consists of the following main components:
- Rear suspension support produced with optimized weight/rigidity ratio (the FWD version has greater optimization of the ratio to achieve more efficient consumption).
- Coil springs optimized along the thrust axis and able to contain side loads. The springs are made of high-strength-steel in order to minimize the weight with consequent benefits in terms of consumption.
- Spring isolators between the springs and their base mountings in order to reduce noise.
- Telescopic shock absorbers with high lateral rigidity which enhances ride quality.
- Anti-roll bar connecting rod.
