Removal And Installation: Removal

WARNING: This page is about a different car, the 2020 Jeep Renegade. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and properly support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
  2. Remove the left front tire and wheel assembly. Refer to REMOVAL AND INSTALLATION .
  3. Remove the left front fender splash shield. Refer to SHIELD, SPLASH, FRONT WHEELHOUSE, REMOVAL AND INSTALLATION .
    GC0173331Courtesy of CHRYSLER GROUP, LLC
  4. Remove the eleven cover plate bolts (1) and the cover plate (2).
  5. Clean the mating surfaces.
