Section 1 (NV241 Or Transfer Case (Service Information)): Assembly: Yoke
WARNING: This page is about a different variant/trim than selected.
 Courtesy of CHRYSLER GROUP, LLC
|
| 1 - FRONT OUTPUT SHAFT |
| 2 - FLANGE SEAL |
- Install yoke seal (2) onto front shaft (1).
 Courtesy of CHRYSLER GROUP, LLC
|
| 1 - TRANSFER CASE |
| 2 - FRONT YOKE |
- Install yoke (2) onto front shaft. Then install and tighten a new yoke nut to 122-176 N.m (90-130 ft. lbs.) torque. Never re-use a yoke nut.
