Link, Camber: Description

WARNING: This page is about a different car, the 2017 Jeep Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
GC0159875Courtesy of CHRYSLER GROUP, LLC

The camber link (1) is connected between the cradle and the front of the knuckle with a bonded bushing on each end. The bushings are serviced with a new link only. On the knuckle side of the link, the bushing is not between two parts of a bracket. Because of this the bolt (2) has a captive washer that will hold the bushing/link in place if the bonding were to separate from the link. Make sure that the proper bolts and nuts are used when servicing.
