Seat Belt-Retractor TENSIONER-Passenger (D6676A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: F760510

Part Description: Not Available

Connector No: D6676A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Seat Belt-Retractor Tensioner-Passenger Connector End View

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner-Passenger Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R54

LB/YL

0.50

PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

R56

LB/DG

0.50

PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
