Lamp, Side Repeater: Installation: Bulb
WARNING: This page is about a different car, the 2014 Dodge Journey. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION:
Always use the correct bulb size and type for replacement. An incorrect bulb size or type may overheat and cause damage to the lamp, the socket or the lamp wiring.
NOTE:
Side repeater lamps are used only on vehicles manufactured for certain export markets where they are required.
- Align the base of the bulb (3) with the socket (1).
- Push the bulb straight into the socket until the base is firmly seated.
- Be certain that a rubber O-ring seal (2) is properly installed and in good condition around the base of the bulb socket.
- Align the socket and bulb with the keyed opening on the back of the side repeater lamp lens/housing (4).
- Insert the socket and bulb into the housing until the socket is firmly seated.
- Rotate the socket clockwise about 30 degrees to lock it into place.
- Reinstall the side repeater lamp into the fender mounting hole. Refer to LAMP, SIDE REPEATER, INSTALLATION .
- Reconnect the battery negative cable.
