Motor, Sunroof, With Control Unit: Removal: Removal

WARNING: This page is about a different car, the 2014 Dodge Journey. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Electrical Connector, Motor Bracket, Motor Assembly & Screws

Courtesy of CHRYSLER GROUP, LLC

1 - ELECTRICAL CONNECTOR

2 - MODULE ASSEMBLY

3 - DRIVE MOTOR

4 - MOUNTING SCREWS

Drop headliner to dash. Refer to HEADLINER, REMOVAL .
Disconnect the electrical connector (1).
Remove three motor assembly attaching screws (4) from bottom side of motor assembly (3) and remove motor assembly from the motor bracket.
