2.8L Diesel

WARNING: This page is about a different car, the 2016 Jeep Wrangler and 2015 Jeep Wrangler. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Turbo Air Inlet Tube

Courtesy of CHRYSLER GROUP, LLC

Siphon out as much power steering fluid as possible.
Remove the air cleaner box.
Remove the turbo air inlet tube (1).

Fig 2: Removing/Installing Steering Pump - 2.8L
Courtesy of CHRYSLER GROUP, LLC
Remove the serpentine drive belt.
Remove the three bolts (4) securing the pulley (3) to the pump (2).
Remove the power steering hoses (1, 6).

Fig 3: Mounting Bolts
Courtesy of CHRYSLER GROUP, LLC
Remove the three bolts (2) securing the pump (1) to the engine.
Remove the pump (1) from the vehicle.
