Rear Door

WARNING: This page is about a different car, the 2016 Dodge Journey and 2015 Dodge Journey. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Wire Harness Connector, Low Frequency (LF) Antenna, Two Screws & Two Plastic Nuts

Courtesy of CHRYSLER GROUP, LLC

Check to be certain that the two plastic nuts (1) are in good condition and properly installed in the rear door.
Position the Low Frequency (LF) antenna (2) to the rear door.
Install and tighten the two screws (3) that secure the LF antenna to the two plastic nuts in the rear door. Tighten the screws securely.
Reconnect the wire harness connector (4) to the connector receptacle for the LF antenna.
Reinstall the trim panel onto the inside of the rear door. Refer to PANEL, REAR DOOR TRIM, INSTALLATION .
Reconnect the battery negative cable.
