C0020-35-Abs Pump Motor Control - Signal High Time > Maximum: Notes

WARNING: This page is about a different car, the 2016 Dodge Journey and 2015 Dodge Journey. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Ignition Run/Start Input Circuit Wiring Diagram

Courtesy of CHRYSLER GROUP, LLC

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

NOTE:

If DTC C0020-16 is present, perform the diagnostics for this DTC before continuing with this diagnostic procedure.
