Switch-Hood Ajar 2 (D2351A)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 04801212 AA

Part Description: INS ASSY

Connector No: D2351A

Option: ~~

Repair Kit Part Number: 05017129AA

Cavity Count: 2

Fig 1: Switch-Hood Ajar 2 Connector End View

GCWD1025385

Courtesy of CHRYSLER

Fig 2: Switch-Hood Ajar 2 Component Location

GCWD1050104

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K806

DB/BR

20

STOP START HOOD AJAR SW SIG

N/A

2

Z905

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
