Solenoid-Camshaft 1/1 Position (D64A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: F495100

Part Description: Not Available

Connector No: D64A

Option: ~~

Repair Kit Part Number: 68149290AA

Cavity Count: 2

Fig 1: Solenoid-Camshaft 1/1 Position Connector End View

Courtesy of CHRYSLER

Fig 2: Solenoid-Camshaft 1/1 Position Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K76

BR/WT

VVT INTAKE CONTROL

N/A

Z902

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
