Relay-Cabin Heater 1 (D805A)

Harness-Family: Dash

Color: LT. GRAY

Gender: FEMALE

Part Number: 12065686

Part Description: 5-WAY RELAY INSULATOR

Connector No: D805A

Option: ~~

Repair Kit Part Number: 68142156AA

Cavity Count: 5

Fig 1: Relay-Cabin Heater 1 Connector End View

GCWD1025463

Courtesy of CHRYSLER

Fig 2: Relay-Cabin Heater 1 Component Location

GCWD1051530

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

30

A281

RD/GY

10

FUSED B(+)

N/A

85

W24

BR/OR

20

FUSED RUN RELAY OUTPUT

N/A

86

K360

GY/BR

20

PTC 1 RELAY CONTROL

N/A

87

A285

RD/DB

10

CABIN HEATER RELAY 1 OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
