Radio C5 (Standard) (D3843E)

Harness-Family: Antenna_GPS

Color: BLUE

Gender: FEMALE

Part Number: 638832-3

Part Description: FAKRA CONNECTOR KIT, 50 OHM, RG-174, SMB

Connector No: D3843E

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Radio C5 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Radio C5 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

WT/LB

GPS ANTENNA SIGNAL

N/A

D108

LB/WT

ANTENNA GPS SHIELD

N/A

⁽¹⁾	Pins not listed are not used for this connector
