Lamp-Park/Turn-Right Front (Except Export) (D4557A)

Harness-Family: Headlamp

Color: BLACK

Gender: FEMALE

Part Number: 7287-0959-30

Part Description: 3P YESC RP SUB ASSY W/ SIDE LOCK AND CPA

Connector No: D4557A

Option: EXCEPT EXPORT

Repair Kit Part Number: 68065016AA

Cavity Count: 3

Fig 1: Lamp-Park/turn-Right Front Connector End View (Except Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Park/Turn-Right Front Component Location (Except Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L160

WT/PK

RIGHT FRONT TURN SIGNAL CONTROL

N/A

L60

WT/TN

RIGHT FRONT TURN LAMP DRIVER

N/A

Z904

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
