Lamp-Headlamp-Right C3 (D4540C)

Harness-Family: Headlamp

Color: BLACK

Gender: FEMALE

Part Number: 18264000000

Part Description: 3-WAY LOAD LEVEL SENSOR

Connector No: D4540C

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Lamp-Headlamp-Right C3 Connector End View

GCWD1052486

Courtesy of CHRYSLER

Fig 2: Lamp-Headlamp-Right C3 Component Location

GCWD1051906

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

L13

WT/YL

20

HEADLAMP LEVEL SENSOR SIGNAL

N/A

2

L135

WT

20

HEADLAMP LEVEL CONTROL SIGNAL

N/A

3

Z904

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
