Horn 2 C1 (Except Export) (D5906A)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 520895-1

Part Description: INSL-POS LKNG 1/4 (FEM)

Connector No: D5906A

Option: EXCEPT EXPORT

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Horn 2 C1 Connector End View (Except Export)

Courtesy of CHRYSLER

Fig 2: Horn 2 C1 Component Location (Except Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X22

GY/LB

FUSED HORN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
