Horn 1 C2 (D5905B)

Harness-Family: Headlamp

Color: BLACK

Gender: FEMALE

Part Number: 520895-1

Part Description: INSL-POS LKNG 1/4 (FEM)

Connector No: D5905B

Option: ~~

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Horn 1 C2 Connector End View

GCWD1006399

Courtesy of CHRYSLER

Fig 2: Horn 1 C2 Component Location

GCWD1051170

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z904

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
