Horn 1 C1 (D5905A)

Harness-Family: Headlamp

Color: BLACK

Gender: FEMALE

Part Number: 520895-1

Part Description: INSL-POS LKNG 1/4 (FEM)

Connector No: D5905A

Option: ~~

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Horn 1 C1 Connector End View

GCWD1006399

Courtesy of CHRYSLER

Fig 2: Horn 1 C1 Component Location

GCWD1051169

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

X21

GY/YL

20

FUSED HORN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
