Heater-Crankcase Vent (D6700A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: 09 4412 11

Part Description: RECEPTACLE HOUSING 2 X SLK 2.8 ELA

Connector No: D6700A

Option: ~~

Repair Kit Part Number: 68032275AB

Cavity Count: 2

Fig 1: Heater-Crankcase Vent Connector End View

Courtesy of CHRYSLER

Fig 2: Heater-Crankcase Vent Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z906

GROUND

N/A

F344

BR/GY

FUSED ASD RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
