Seat Belt-Buckle TENSIONER-Passenger (D6746)

Harness-Family: Seat_Pass

Color: YELLOW

Gender: FEMALE

Part Number: 54550415

Part Description: APEX CONNECTOR - SHORTING BAR APEX

Connector No: D6746

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Seat Belt-Buckle Tensioner-Passenger Connector End View

Courtesy of CHRYSLER

Fig 2: Seat Belt-Buckle Tensioner-Passenger Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R54

LB/YL

PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

R56

LB/DG

PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

R58

LB/GY

PASSENGER SEAT BELT SWITCH SENSE

N/A

R60

LB/TN

PASS SEAT BELT BUCKLE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
