Relay-Hid Headlamps-Left (D8811)

Harness-Family: PDC_UNDERHOOD

Color: BLACK

Gender: MALE

Part Number: Relay_Micro

Part Description: Not Available

Connector No: D8811

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-Hid Headlamps-Left Connector End View

Courtesy of CHRYSLER

Fig 2: Relay-Hid Headlamps-Left Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

INTERNAL

B(+)

N/A

L311

INTERNAL

LEFT HEADLAMP RELAY CONTROL

N/A

Z909

INTERNAL

GROUND

N/A

L303

INTERNAL

LEFT HID LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
