Motor-Sunroof Shade (Standard) (D2700A)

Harness-Family: Sunroof

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-8398-40

Part Description: HYBRID YESC CONNECTOR SUBASSY

Connector No: D2700A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 14

Fig 1: Motor-Sunroof Shade Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Sunroof Shade Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A906

2.0

FUSED B(+)

N/A

F981

PK/YL

0.35

FUSED IGNITION RUN/ACCESSORY CONTROL OUTPUT

N/A

Z923

2.0

GROUND

N/A

Z911

GROUND

N/A

Q556

OR/GY

0.35

SUNROOF SHADE PWR OPEN (+)

N/A

Q56

OR/VT

0.35

SUNROOF SHADE PWR CLOSE (+)

N/A

D270

OR/BK

0.35

SUNROOF DIAGNOSTIC

N/A

⁽¹⁾	Pins not listed are not used for this connector
