Motor-Seat Lumbar-Up/Down-Passenger (Standard) (D2642A)

Harness-Family: Seat_Pass_2

Color: BLACK

Gender: MALE

Part Number: ~~

Part Description: Not Available

Connector No: D2642A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Motor-Seat Lumbar-Up/down-Passenger Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Seat Lumbar-Up/down-Passenger Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P173

LG/YL

LUMBAR DOWNWARD PASS

N/A

P171

LG/VT

LUMBAR UPWARD PASS

N/A

⁽¹⁾	Pins not listed are not used for this connector
