Motor-Seat Adjuster-Front Passenger Vertical (Standard) (D3032A)

Harness-Family: Seat_Cshn_Pass

Color: GRAY

Gender: FEMALE

Part Number: 4P RECEPTACLE HOUSING - 2X JPT + 2X MT3

Part Description: Not Available

Connector No: D3032A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Motor-Seat Adjuster-Front Passenger Vertical Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Seat Adjuster-Front Passenger Vertical Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P18

LG/OR

PASSENGER SEAT FRONT UP DRIVER

N/A

P20

LG/LB

PASSENGER SEAT FRONT RISER DOWN DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
