Motor-Power Steering Pump C1 (Standard) (D2435A)

Harness-Family: HDLP_Dash

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7287-1990-30

Part Description: 2P 9.5 SEALED SUB-ASSEMBLY W/CPA

Connector No: D2435A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Motor-Power Steering Pump C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Power Steering Pump C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A951

FUSED B(+)

N/A

Z907

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
