Lamp-Courtesy-Lower Left (Bin) (D4520A)

Harness-Family: Console

Color: ~~

Gender: FEMALE

Part Number: 7283-6443-40

Part Description: 2P KAIZEN YESC 1.5MM Female SUB ASSEMBLY

Connector No: D4520A

Option: BIN

Repair Kit Part Number: 68065023AA

Cavity Count: 2

Fig 1: Lamp-Courtesy-Lower Left Connector End View (BIN)

Courtesy of CHRYSLER

Fig 2: Lamp-Courtesy-Lower Left Component Location (BIN)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

M27

YL/LB

READING LAMPS DRIVER

N/A

Z911

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
