Lamp-Assembly-Right Front C3 (AHLM, Hid) (D6606C)

Harness-Family: Front_End_Module

Color: ~~

Gender: MALE

Part Number: 33471-0401

Part Description: Not Available

Connector No: D6606C

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Lamp-Assembly-Right Front C3 (ahlm, hid) Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Right Front C3 (ahlm, hid) Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L44

WT/TN

RIGHT LOW BEAM DRIVER

N/A

Z909

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
