Heater-Seat Back-Right Rear (D2400A)

Harness-Family: RT_RR_CUSHION

Color: GREEN

Gender: MALE

Part Number: 7282-6444-60

Part Description: KAIZEN YESC SUB ASSEMBLY

Connector No: D2400A

Option: Standard

Repair Kit Part Number: 68087932AA

Cavity Count: 2

Fig 1: Heater-Seat Back-Right Rear Connector End View

Courtesy of CHRYSLER

Fig 2: Heater-Seat Back-Right Rear Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P178

RIGHT REAR SEAT HEATER CONTROL

N/A

Z919

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
