Vent-Seat Back-Right C1 (D6660A)

Harness-Family: Seat_Heater_RT

Color: GREEN

Gender: FEMALE

Part Number: ~~

Part Description: Not Available

Connector No: D6660A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Vent-Seat Back-Right C1 Component Location

GCWD1016973

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

P188

YL

18

RIGHT FRONT SEAT HEATER CONTROL

N/A

2

Z919

BK

18

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
