Vent-Seat Back-Left C2 (D6659B)

Harness-Family: Seat_Driver_2

Color: LIGHT GRAY

Gender: MALE

Part Number: 7282-6443-40

Part Description: 2P KAIZEN YESC 1.5MM MALE SUB ASSEMBLY

Connector No: D6659B

Option: ~~

Repair Kit Part Number: 68065022AA

Cavity Count: 2

Fig 1: Vent-Seat Back-Left C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Vent-Seat Back-Left C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P421

LG/OR

LEFT SEAT VENT FEED

N/A

P921

OR/LG

LEFT SEAT VENT RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
