Throttle Body (5.7L/6.4L) (D6701A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 1-1419168-1

Part Description: Not Available

Connector No: D6701A

Option: 5.7L/6.4L

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Throttle Body Connector End View (5.7L/6.4L)

Courtesy of CHRYSLER

Fig 2: Throttle Body Component Location (5.7L/6.4L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K447

TN/YL

ETC MOTOR (+)

N/A

K448

TN/OR

ETC MOTOR (-)

N/A

K122

BR/DG

TP 2 SIGNAL

N/A

F855

PK/YL

5 VOLT SUPPLY

N/A

K22

BR/OR

TP 1 SIGNAL

N/A

K922

BR/DB

TP SENSOR RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
