Switch-Seat Belt Buckle-Passenger (D2283A)

Harness-Family: Seat_Cshn_Pass

Color: LIGHT GRAY

Gender: MALE

Part Number: 2P KAIZEN YESC 1.5MM MALE SUB ASSEMBLY

Part Description: Not Available

Connector No: D2283A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Seat Belt Buckle-Passenger Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt Buckle-Passenger Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R58

LG/GY

PASSENGER SEAT BELT SWITCH SENSE

N/A

R60

LG/TN

PASS SEAT BELT BUCKLE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
