Connector-Star Can IHS IP C8 (D2601H)

Harness-Family: IP

Color: Black

Gender: MALE

Part Number: 1-1418639-1

Part Description: Not Available

Connector No: D2601H

Option: ~~

Repair Kit Part Number: 68137879AA

Cavity Count: 2

Fig 1: Connector-Star Can Ihs Ip C8 Connector End View

Courtesy of CHRYSLER

Fig 2: Connector-Star Can Ihs Ip C8 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D163

WT/DB

CAN IHS (+) - COMFORT SEAT WHEEL MODULE

N/A

D164

CAN IHS (-) - COMFORT SEAT WHEEL MODULE

N/A

⁽¹⁾	Pins not listed are not used for this connector
